Aluminium, stainless steelWith sealing ringVariants recommended for production systems for manufacturing lithium-ion batteries

Feature ValueSize of pack 10Conforms to standard DIN 908LABS (PWIS) conformity VDMA24364-B1/B2-LNominal torque 11 NmTolerance for nominal tightening torque ± 10%Product weight 15 gType of mounting Internal hexagon, size 6 mmPneumatic connection, port 1 Male thread G1/4Note on materials RoHS-compliantMaterial blanking plug Galvanised steelMaterial o-ring PA TPE-U(PUR)

B-1/2

B-1/8

Standard seriesWide range of variants: wide selection for maximum flexibility in standard applicationsPBT and nickel-plated brass

Standard seriesMany variants: Wide range of options for standard applications for maximum flexibilityPBT and nickel-plated brassWorking medium: compressed air, vacuum, water. For the suitability of water, see Manufacturer's Declaration of Conformity, see www.festo.com/certificates/QSStraight shape, L-shape, T-shape, at 45° angle, X-shape, Y-shape, push-in bulkhead connector

SizeM6Conforms to standardDIN 71752ISO 8140Threaded connectionFemale thread M6Corrosion resistance class CRC1 - Low corrosion stressLABS (PWIS) conformityVDMA24364-B2-LSuitability for the production of Li-ion batteriesMetals with more than 1% by mass of copper are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coilsAmbient temperature-40 °C ... 150 °CProduct weight22 gNote on materialsRoHS-compliantMaterial boltSteelGalvanisedMaterial clevisSteelGalvanisedMaterial nutSteelGalvanised

Compact design, polymer or die-castBarbed fitting or threaded connectionOperating medium compressed air

U-1/2

Installation locationOptionalsymbol00991473Work pressure0 Mpa ... 1 MpaWork pressure0 bar ... 10 barFlow to the atmosphere3300 l/minWorking mediumCompressed air according to ISO 8573-1:2010 [7:-:-]Description of the working and pilot mediaIt can be operated with lubricating mediaPaint wetting defective substance (PWIS) complianceVDMA24364-B1/B2-LSound pressure level76 dB(A)Ambient temperature-10 °C ... 70 °CProduct weight7.7 gPneumatic interfaceG1/4The material of the hydraulic shock absorber insertPEMaterial Description:RoHS compliant

Installation locationOptionalsymbol00991473Work pressure0 Mpa ... 1 MpaWork pressure0 bar ... 10 barFlow to the atmosphere3300 l/minWorking mediumCompressed air according to ISO 8573-1:2010 [7:-:-]Description of the working and pilot mediaIt can be operated with lubricating mediaPaint wetting defective substance (PWIS) complianceVDMA24364-B1/B2-LSound pressure level76 dB(A)Ambient temperature-10 °C ... 70 °CProduct weight7.7 gPneumatic interfaceG1/4The material of the hydraulic shock absorber insertPEMaterial Description:RoHS compliant

U-3/8

specification40Meets standardsISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI 10290)Corrosion resistance rating CRC1 - Low corrosion resistancePaint wetting defective substance (PWIS) complianceVDMA24364-B2-LAmbient temperature-40 °C ... 150 °CProduct weight291 gMaterial Description:RoHS compliantMounting MaterialsteelgalvanizeScrew materialsteelgalvanize

specification40Meets standardsISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI 10290)Corrosion resistance rating CRC1 - Low corrosion resistancePaint wetting defective substance (PWIS) complianceVDMA24364-B2-LAmbient temperature-40 °C ... 150 °CProduct weight291 gMaterial Description:RoHS compliantMounting MaterialsteelgalvanizeScrew materialsteelgalvanize

Grid dimension 40mmTo build a regulator manifold with through air supply for pressure ranges that can be adjusted independently of one anotherGood control characteristics with minimal pressure hysteresis and primary pressure compensation

Feature ValueSize 6Series MSCorrosion resistance class CRC 2 - Moderate corrosion stressLABS (PWIS) conformity VDMA24364-B1/B2-LMedia temperature -10 °C ... 60 °CProduct weight 121 gNote on materials RoHS-compliantMaterial screws  SteelMaterial bracket  Steel

Size6SeriesMSCorrosion resistance class CRC2 - Moderate corrosion stressLABS (PWIS) conformityVDMA24364-B1/B2-LMedia temperature-10 °C ... 60 °CProduct weight300 gPneumatic connection, port 1G1/2Pneumatic connection, port 2G1/2Note on materialsRoHS-compliantMaterial sub-baseDie-cast aluminiumMaterial sealsNBR

Size9SeriesMSCorrosion resistance class CRC2 - Moderate corrosion stressLABS (PWIS) conformityVDMA24364-B1/B2-LMedia temperature-10 °C ... 60 °CProduct weight110 gNote on materialsRoHS-compliantMaterial sealsNBRMaterial hollow boltDie-cast aluminiumMaterial module connectorDie-cast aluminiumMaterial screwsSteel

Size9SeriesMSCorrosion resistance class CRC2 - Moderate corrosion stressLABS (PWIS) conformityVDMA24364-B1/B2-LMedia temperature-10 °C ... 60 °CProduct weight180 gNote on materialsRoHS-compliantMaterial sealsNBRMaterial hollow boltDie-cast aluminiumMaterial module connectorDie-cast aluminiumMaterial screwsSteelMaterial bracketDie-cast aluminium

Shut-off valve, manually operatedIn-line installationFemale thread at both ends

Corrosion resistance class CRC1 - Low corrosion stressLABS (PWIS) conformityVDMA24364-B1/B2-LAmbient temperature-10 °C ... 80 °CNominal torque9 NmTolerance for nominal tightening torque± 20%Product weight23 gType of mountingExternal hexagon, size 17 mmPneumatic connection, port 1Male thread G1/4Pneumatic connection, port 2For tubing outside diameter of 8 mmColour of release ringBlueMaterial screwed plugNickel-plated brassNote on materialsRoHS-compliantMaterial housingPBTMaterial release ringPOMMaterial tubing sealNBRMaterial tubing clamp componentHigh-alloy stainless steel

Standard seriesMany variants: Wide range of options for standard applications for maximum flexibilityPBT and nickel-plated brassWorking medium: compressed air, vacuum, water. For the suitability of water, see Manufacturer's Declaration of Conformity, see www.festo.com/certificates/QSStraight shape, L-shape, T-shape, at 45° angle, X-shape, Y-shape, push-in bulkhead connector

Corrosion-resistantCompensation of pressure fluctuations and as accumulators in the event of sudden air consumptionProviding large quantities of compressed air for supplying fast pulsing drives

Corrosion-resistantCompensation of pressure fluctuations and as accumulators in the event of sudden air consumptionProviding large quantities of compressed air for supplying fast pulsing drives

For valve terminals VTUG, MPA-L, VTOCCan be expanded into the installation system CTELFieldbus-typical LEDs, interfaces and switching elements

Valve functionOne-way throttling functionP-port connection, port 1QS-6Air connection, port 2QS-6Adjusting elementsKnurled screwsInstallation:Panel mountingWith through-holesWith attachmentsEither:Standard nominal flow in the flow control direction245 l/minStandard nominal traffic in the blockade direction430 l/minWork pressure0.2 bar ... 10 barAmbient temperature-10 °C ... 60 °CHousing materialReinforced polyamideExplosion proofThe information in the certificate must be followed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)Installation locationOptionalsymbol00991453Working mediumCompressed air according to ISO 8573-1:2010 [7:4:4]Description of the working and pilot mediaCan be operated with lubricating medium (must be lubricated all the time thereafter)Paint wetting defective substance (PWIS) complianceVDMA24364-B1/B2-LMedium temperature-10 °C ... 60 °CProduct weight22 gMaterial Description:RoHS compliantSeal materialNBRRelease ring materialPOMKnurled head materialReinforced polyamideAdjust the screw materialHigh-alloy steel

Feature ValueSize 100Conforms to standard ISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI10290)Corrosion resistance class CRC 2 - Moderate corrosion stressLABS (PWIS) conformity VDMA24364-B2-LAmbient temperature -40 °C ... 150 °CProduct weight 1009 gNote on materials RoHS-compliantMaterial mounting SteelGalvanisedMaterial screws Steel Galvanised

Grid dimension 42mmProportional lubricator with precision oil meteringQuick and easy top-up even under pressure

Wide range of variants for customised applicationsGood running performance and long service lifeSelf-adjusting pneumatic end-position cushioning saves time during commissioning and adapts optimally to load and speed changes

Grid dimension 40mmTo build a regulator manifold with through air supply for pressure ranges that can be adjusted independently of one anotherGood control characteristics with minimal pressure hysteresis and primary pressure compensation
